Product Summary
The 70474140 is an axial lead metallized polypropylene capacitor which is available in bulk or on tape and reel for automatic insertion. The tape wrap and epoxy end fill construction meets UL510 (outer wrap) and UL94V0 (epoxy). The 70474140 is non-inductive with low ESR and high current capability for switch-mode power supply applications.
Parametrics
70474140 specifications: (1)Capacitance Range: 0.001 μF to 4.7 μF; (2)Voltage Range: 160 to 630 Vdc (90 to 250 Vac, 60 Hz); (3)Capacitance Tolerance: ±5%, ±10%, ±20%; (4)Operating Temperature Range: –55 ℃ to +105 ℃; (5)Dielectric Withstand Voltage: 1.6 × rated voltage for 2 s @ +25 ℃ ±5 ℃; (6)Insulation Resistance: 100,000 MΩ × μF, 200,000 MΩ Min; (7)Self Inductance: 1 nH ma×. per 1 mm lead and body length; (8)Life Test: 1000 hrs @ 85 ℃ 1.25 × Vn; (9)Damp Heat Test: 95% RH @ +40 ℃ for 21 days; (10)Soldering: 260 ℃ ±5 ℃ for 10 s ±1 s.
Features
70474140 features: (1)Low ESR; (2)High current; (3)Available on tape and reel or bulk; (4)Epoxy end fill meets UL94V-0; (5)Non inductively wound; (6)Flame retardant outer wrap meets UL510.
