AMS1117-3.3

1A, low dropout voltage regulator, SOT223, Line Regulation, Output Current of 1A, Load Regulation

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.04~0.08 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.04~0.08

PartNumber:: AMS1117-3.3

Brand:: Advanced Monolithic Systems - AMS | Pack: SOT | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Berry's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-07-17

From Other Seller

Part Number:AMS1117-3.3
US $0.04 - 0.08
ECA1HHG100

US $10.00 - 10.00 / Piece
(0) Remove
CM2030-A0TR

US $0.92 - 2.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AMS1117-3.3 is a 1A low dropout voltage regulator. It is designed to provide 1A output current and to operate down to 1V input-to-output differential. The dropout voltage of the device is guaranteed maximum 1.3V at maximum output current, decreasing at lower load currents. On-chip trimming adjusts the reference voltage to 1%. Current limit is also trimmed, minimizing the stress under overload conditions on both the regulator and power source circuitry. The AMS1117-3.3 is pin compatible with other three-terminal SCSI regulators and are offered in the low profile surface mount SOT-223 package, in the 8L SOIC package and in the TO-252 (DPAK) plastic package. The applications of the AMS1117-3.3 are High Efficiency Linear Regulators, Post Regulators for Switching Supplies, 5V to 3.3V Linear Regulator, Battery Chargers, Active SCSI Terminators, Power Management for Notebook, Battery Powered Instrumentation.

Parametrics

AMS1117-3.3 absolute maximum ratings: (1)Power Dissipation:Internally limited; (2)Input Voltage:15V; (3)Operating Junction Temperature: Control Section:0℃ to 125℃, Power Transistor:0℃ to 150℃; (4)Storage temperature:- 65℃ to +150℃ ; (5)Soldering information:Lead Temperature (25 sec):265℃; (6)Thermal Resistance:φJA = 90℃/W.

Features

AMS1117-3.3 features: (1)Three Terminal Adjustable or Fixed Voltages: 1.5V, 1.8V, 2.5V, 2.85V, 3.3V and 5.0V ; (2)Output Current of 1A ; (3)Operates Down to 1V Dropout ; (4)Line Regulation: 0.2% Max. ; (5)Load Regulation: 0.4% Max. ; (6)SOT-223, TO-252 and SO-8 package available .
