Product Summary
The IR3086AMTRPBF is a phase IC combined with an IR XPhaseTM Control IC which provides a full featured and flexible way to implement power solutions for the latest high performance CPUs and ASICs. The XPhaseTM architecture results in a power supply that is smaller, less expensive, and easier to design while providing higher efficiency than conventional approaches.
Parametrics
IR3086AMTRPBF maximum ratings: (1)Operating Junction Temperatur: 150℃; (2)Storage Temperature Range: -65 to 150℃; (3)ESD Rating: HBM Class 1C JEDEC standard.
Features
IR3086AMTRPBF features: (1)2.5A Average Gate Drive Current; (2)Loss-Less Inductor Current Sense; (3)Internal Inductor DCR Temperature Compensation; (4)Programmable Phase Delay; (5)Programmable Feed-Forward Voltage Mode PWM Ramp; (6)Sub 100ns Minimum Pulse Width supports 1MHz per-phase operation; (7)Current Sense Amplifier drives a single wire Average Current Share Bus; (8)Current Share Amplifier reduces PWM Ramp slope to ensure sharing between phases.
