Product Summary
The PT2313L is a four-channel digital control audio processor utilizing CMOS Technology. Volume, Bass, Treble and Balance, Front/Rear Fader Processor are incorporated into a single chip. Loudness Function and Selectable Input Gain are also provided to build a highly effective electronic audio processor having the highest performance and reliability with the least external components. All functions are programmable using the I2C Bus. The applications of the PT2313L include: Car Stereo (Audio); Hi-Fi Audio System.
Features
PT2313L features: (1)CMOS Technology; (2)Least External Components; (3)Treble and Bass Control; (4)Loudness Function; (5)3 Stereo Inputs with Selectable Input Gain; (6)Input/Output for External Noise Reduction System/Equalizer; (7)4 Independent Speaker Controls for Fader and Balance; (8)Independent Mute Function; (9)Volume Control in 1.25 dB/step; (10)Low Distortion; (11)Low Noise and DC Stepping; (12)Controlled by I2C Bus Micro-Processor Interface; (13)Pin-to-pin Compatible with TDA7313.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 PT2313L |
Other |
|
Data Sheet |
Negotiable |
|
||||
