Product Summary

The S29AL016J70TFI02 is a 16 Mbit, 3.0 Volt-only Flash memory organized as 2,097,152 bytes or 1,048,576 words. The device is offered in 48-ball Fine-pitch BGA (0.8 mm pitch), 64-ball Fortified BGA (1.0 mm pitch) and 48-pin TSOP packages.

Parametrics

Absolute maximum ratings: (1)Storage Temperature Plastic Packages:–65℃ to +150℃; (2)Ambient Temperature with Power Applied:–65℃ to +125℃; (3)Voltage with Respect to Ground: VCC:–0.5V to +4.0V, A9, OE#, and RESET#:–0.5V to +12.5V,All other pins:–0.5V to VCC+0.5V; (4)Output Short Circuit Current:200mA.

Features

Features: (1)Single Power Supply Operation; (2)Manufactured on 110 nm Process Technology; (3)Secured Silicon Sector region; (4)Flexible Sector Architecture; (5)Sectors can be locked in-system or via programming equipment; (6)Unlock Bypass Program Command; (7)Top or Bottom Boot Block Configurations Available; (8)Compatibility with JEDEC standards; (9)High Performance; (10)Ultra Low Power Consumption (typical values at 5 MHz); (11)Cycling Endurance: 1,000,000 cycles per sector typical; (12)Data Retention: 20 years typical.

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
S29AL016J70TFI020
S29AL016J70TFI020
Spansion
Flash 16MB CMOS 3.0V 70ns BTM SECTOR PBF
Data Sheet
0-1: $0.54
1-25: $0.52
25-100: $0.50
100-500: $0.48
S29AL016J70TFI023
S29AL016J70TFI023
Spansion
Flash IC 16M 3V (2MX8BIT/1 MX16BIT)
Data Sheet
0-1000: $0.53
