Product Summary

The CD4011BCMX is a Quad 2-Input NAND Buffered B Series Gate. It has equal source and sink current capabilities and conform to standard B series output drive. The CD4011BCMX also has buffered outputs which improve transfer characteristics by providing very high gain. All inputs are protected against static discharge with diodes to VDD and VSS.

Parametrics

CD4011BCMX absolute maximum ratings: (1)Voltage at any Pin:-0.5V to VDD +0.5V; (2)Power Dissipation (PD): Dual-In-Line:700mW, Small Outline:500mW; (3)VDD Range:-0.5VDC to +18VDC; (4)Storage Temperature (TS):-65℃ to +150℃; (5)Lead Temperature (TL)(Soldering, 10 seconds):260℃.

Features

CD4011BCMX features: (1)Low power TTL: Fan out of 2 driving 74L compatibility: or 1 driving 74LS; (2)5V–10V–15V parametric ratings; (3)Symmetrical output characteristics; (4)Maximum input leakage 1 μA at 15V over full temperature range.

Diagrams

CD4011BCMX Connection Diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
CD4011BCMX
CD4011BCMX

IC GATE NAND QUAD 2INPUT 14SOIC
Data Sheet
Negotiable
