Product Summary
The IRF7821TR is a kind of power MOSFET, which is also a kind of international rectifier. The IRF7821TR high frequency point-of-load synchronous buck converter is suitable for applications in networking and computing systems.
Parametrics
IRF7821TR maximum ratings: (1)Drain-to-Source Voltage: 30V; (2)Gate-to-Source Voltage: ±20V; (3)TA = 25℃, Continuous Drain Current, VGS = 10V: 13.6A; (4)TA = 70℃, Continuous Drain Current, VGS = 10V:11 A; (5)Pulsed Drain Current : 100A; (6)TA = 25℃, Power Dissipation: 2.5 W; (7)TA = 70℃, Power Dissipation: 1.6 W; (8)Linear Derating Factor: 0.02 W/℃; (9)Operating Junction and Storage Temperature Range: -55 to +155℃.
Features
IRF7821TR features: (1)Very Low RDS(on) at 4.5V VGS; (2)Low Gate Charge; (3)Fully Characterized Avalanche Voltage and Current.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 IRF7821TR |
|
MOSFET N-CH 30V 13.6A 8-SOIC |
Data Sheet |
Negotiable |
|
||||||||||||
 |
IRF7821TRPBF |
International Rectifier |
MOSFET MOSFT 30V 13.6A 9.1mOhm 9.3nC |
Data Sheet |
|
|
||||||||||||
