Product Summary

The KTN2222AU-RTK is an epitaxial planar NPN transistor. The applications of it are general purpose application and switching application.

Parametrics

KTN2222AU-RTK absolute maximum ratings: (1)collector-base voltage:75V; (2)collector-emitter voltage:30V; (3)emitter-base voltage:6V; (4)collector current:600mA; (5)collector power dissipation:100mW; (6)junction temperature:150℃; (7)storage temperature range:-55℃ to 150℃.

Features

KTN2222AU-RTK features: (1)low leakage current:ICEX=10nA(max.);VCE=60V, VEB(OFF)=3V; (2)low saturation voltage:VCE(sat)=0.3V(max.);IC=150mA, IB=15mA; (3)complementary to the KTN2907U/2907AU.

Diagrams

KTN2222AU-RTK pin configuration

KTN2222AE
KTN2222AE
