MAX3221ECAE

±15kV, ESD-Protected, 1uA, 3.0V to 5.5V, 250kbps, RS-232 Transceiver, Latchup Free, ESD Protection

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.20~1.60 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.20~1.60

PartNumber:: MAX3221ECAE

Brand:: Maxim Integrated Products - Maxim | Pack: SSOP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Berry's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-07-11

From Other Seller

Part Number:MAX3221ECAE
US $1.20 - 1.60
ECA1HHG220

US $2.00 - 10.00 / Piece
(0) Remove
TMS320C6414TBGLZA7

US $58.00 - 65.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The MAX3221ECAE is a 3V-powered EIA/TIA-232 and V.28/V.24 communication interface with automatic shutdown/wakeup features, high datarate capabilities, and enhanced electrostatic discharge (ESD) protection. All transmitter outputs and receiver inputs of the MAX3221ECAE are protected to ±15kV using IEC 1000-4-2 Air-Gap Discharge, to ±8kV using IEC 1000-4-2 Contact Discharge, and to ±15kV using the Human Body Model. The MAX3221ECAE achieves a 1μA supply current with Maxim revolutionary AutoShutdown. feature. They save power without changes to the existing BIOS or operating system by entering low-power shutdown mode when the RS-232 cable is disconnected, or when the transmitters of the connected peripherals are off. The transceiver of the MAX3221ECAE has a proprietary low-dropout transmitter output stage, delivering true RS-232 performance from a +3.0V to +5.5V supply with a dual charge pump. The charge pump requires only four small 0.1μF capacitors for operation from a +3.3V supply. The MAX3221ECAE is guaranteed to run at data rates of 250kbps while maintaining RS-232 output levels.

Parametrics

MAX3221ECAE absolute maximum ratings: (1)VCC to GND: -0.3V to +6V; (2)V+ to GND: -0.3V to +7V; (3)V- to GND: +0.3V to -7V; (4)V+ + |V-|: +13V; (5)Input Voltages T_IN, EN, FORCEON, FORCEOFF to GND: -0.3V to +6V; (6)R_IN to GND: ±25V; (7)Output Voltages T_OUT to GND: ±13.2V; (8)R_OUT, R2OUTB, INVALID to GND: -0.3V to (VCC + 0.3V); (9)Short-Circuit Duration T_OUT to GND: Continuous; (10)Storage Temperature Range: -65℃ to +160℃; (11)Lead Temperature (soldering, 10sec): +300℃.

Features

MAX3221ECAE features: (1)ESD Protection for RS-232 I/O Pins:±15kV—Human Body Model; ±8kV—IEC1000-4-2, Contact Discharge; ±15kV—IEC1000-4-2, Air-Gap Discharge; (2)Latchup Free; (3)1μA Supply Current; (4)250kbps Guaranteed Data Rate; (5)6V/μs Guaranteed Slew Rate; (6)Meets EIA/TIA-232 Specifications Down to 3.0V; (7)Smallest Single-Supply RS-232 Transceiver; (8)Guaranteed Mouse Driveability; (9)Small 0.1μF Capacitors.
