Product Summary
The NH82801HBM is a Controller. It provides extensive I/O support.
Parametrics
Absolute maximum ratings: (1)Voltage on any 3.3 V Pin with respect to Ground:-0.5V to Vcc3_3+ 0.5V; (2)Voltage on any 5 V Tolerant Pin with respect to Ground (V5REF =5 V):-0.5V to V5REF+0.5V; (3)1.05 V Supply Voltage with respect to VSS:-0.5V to 2.1V; (4)1.25 V Supply Voltage with respect to VSS:-0.5V to 2.1V; (5)1.5 V Supply Voltage with respect to VSS:-0.5V to 2.1V; (6)3.3 V Supply Voltage with respect to VSS:-0.5V to 4.6V; (7)5.0 V Supply Voltage with respect to VSS:-0.5V to 5.5V; (8)V_CPU_IO Supply Voltage with respect to VSS:-0.5V to 2.1V.
Features
Features: (1)ACPI Power Management Logic Support; (2)Enhanced DMA controller, interrupt controller, and timer functions; (3)Integrated IDE controller supports Ultra ATA100/66/33 (Mobile only); (4)Integrated 10/100/1000 GbE MAC with System Defense; (5)Supports Intel High Definition Audio; (6)Supports Intel Matrix Storage Technology; (7)ow Pin Count (LPC) interface; (8)Firmware Hub (FWH) interface support; (9)Serial Peripheral Interface (SPI) support ; (10)Intel Quiet System Technology (Desktop only).
