NH82801HB M

Gigabit Ethernet Controller, BGA, Configurable LED operation, Full wake-up support， 64-bit

Rated 5 Rating 5 | reviews | Write a review

Price:: US $6.80~7.20 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $6.80~7.20

PartNumber:: NH82801HB M

Brand:: Intel Corporation - Intel | Pack: BGA | D/C: 05+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Berry's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-07-26

From Other Seller

Part Number:NH82801HB M
US $6.80 - 7.20
EKXG401ELL6R8MJ16S

US $5.00 - 5.00 / Piece
(0) Remove
ad7716ap

US $1.13 - 1.13 / Piece
(0) Remove
Quantity:

piece

Product Summary

The NH82801HB M is a Gigabit Ethernet Controller. The NH82801HB M is compatible with Intel 10/100 PHY (Intel 82562V Platform LAN Connect device) and GbE PHY (Intel 82566 Gigabit Platform LAN Connect device). The NH82801HB M provides two interfaces: LCI for 10/100 operation and GLCI for GbE operation.The device supports multi speed operation, 10/100/1000 Mb/s. The NH82801HB M provides a system interface via a PCI function. A full memory-mapped or I/O-mapped interface is provided to the software, along with DMA mechanisms for high performance data transfer.

Parametrics

NH82801HB M absolute maximum ratings: (1)Voltage on any 3.3 V Pin with respect to Ground:-0.5V to Vcc3_3 + 0.5V; (2)Voltage on any 5 V Tolerant Pin with respect to Ground (V5REF = 5 V):-0.5V to V5REF + 0.5V; (3)1.05 V Supply Voltage with respect to VSS:-0.5V to 2.1V; (4)1.25 V Supply Voltage with respect to VSS:-0.5V to 2.1V; (5)1.5 V Supply Voltage with respect to VSS:-0.5V to 2.1V; (6)3.3 V Supply Voltage with respect to VSS:-0.5V to 4.6V; (7)5.0 V Supply Voltage with respect to VSS:-0.5V to 5.5V; (8)V_CPU_IO Supply Voltage with respect to VSS:-0.5V to 2.1V.

Features

NH82801HB M features: (1)Configurable LED operation for customization of LED display; (2)IPv4 and IPv6 Checksum Offload support (receive, transmit, and large send); (3)64-bit address master support for system using more than 4 GB of physical memory; (4)Configurable receive and transmit data FIFO, programmable in 1KB increments; (5)Intelligent interrupt generation to enhance driver performance; (6)Compliance with Advanced Configuration and Power Interface and PCI Power Management standards; (7)ACPI register set and power down functionality supporting D0 & D3 states; (8)Full wake-up support (ACPI); (9)Magic Packet wake-up enable with unique MAC address; (10)Fragmented UDP checksum off load for package reassembly.
