OP2177ARZ-REEL7

operational amplifier, SOP8, 36V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.20~1.60 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.20~1.60

PartNumber:: OP2177ARZ-REEL7

Brand:: Analog Devices - ADI | Pack: SOP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Berry's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-07-16

From Other Seller

Part Number:OP2177ARZ-REEL7
US $1.20 - 1.60
2DI240A-055

US $70.00 - 100.00 / Piece
(0) Remove
QM75DY-H

US $16.00 - 30.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The OP2177ARZ-REEL7 is a precision low noise, low input bias current operational amplifier. It features extremely low offset voltage and drift, low input bias current, low noise, and low power consump-tion. Outputs are stable with capacitive loads of over 1000 pF with no external compensation. The applications of the OP2177ARZ-REEL7 include: (1)Wireless base station control circuits; (2)Optical network control circuits; (3)Instrumentation; (4)Sensors and controls: Thermocouples; Resistor thermal detectors (RTDs); Strain bridges; Shunt current measurements; (5)Precision filters.

Parametrics

OP2177ARZ-REEL7 absolute maxing ratings: (1)Supply Voltage: 36 V; (2)Input Voltage: VS- to VS+; (3)Differential Input Voltage: ±Supply Voltage; (4)Storage Temperature Range R, RM, and RU Packages: -65℃ to +150℃; (5)Operating Temperature Range OP1177/OP2177/OP4177: -40℃ to +125℃; (6)Junction Temperature Range R, RM, and RU Packages: -65℃ to +150℃; (7)Lead Temperature, Soldering (10 sec): 300℃.

Features

OP2177ARZ-REEL7 features: (1)Low offset voltage: 60 μV maximum; (2)Very low offset voltage drift: 0.7 μV/℃ maximum; (3)Low input bias current: 2 nA maximum; (4)Low noise: 8 nV/√Hz typical; (5)CMRR, PSRR, and AVO > 120 dB minimum; (6)Low supply current: 400 μA per amplifier; (7)Dual supply operation: ±2.5 V to ±15 V; (8)Unity-gain stable; (9)No phase reversal; (10)Inputs internally protected beyond supply voltage.
