Product Summary
The FDW2501NZ-NL is a Dual N-Channel 2.5V Specified PowerTrench MOSFET. It is a rugged gate version of Fairchild Semiconductor’s advanced PowerTrench process. The FDW2501NZ-NL has been optimized for power management applications with a wide range of gate drive voltage (2.5V to 12V). The applications of the FDW2501NZ-NL are Load switch, Motor drive, DC/DC conversion, Power management.
Parametrics
FDW2501NZ-NL absolute maximum ratings: (1)Drain-Source Voltage:20V ; (2)Gate-Source Voltage:±12V; (3)Drain Current:Continuous:5.5A,Pulsed:30A; (4)Power Dissipation:1.0W or 0.6W; (5)Operating and Storage Junction Temperature Range:–55℃ to +150℃.
Features
FDW2501NZ-NL features: (1)5.5 A, 20 V. RDS(ON) = 18 mΩ @ VGS = 4.5V，RDS(ON) = 25 mΩ @ VGS = 2.5V ; (2)Extended VGSS range (±12V) for battery applications ; (3)ESD protection diode (note 3) ; (4)High performance trench technology for extremely low RDS(ON) ; (5)Low profile TSSOP-8 package .
